Map-1

Gas Fields & Gas Pipeline Map Bangladesh

Major Transmission Pipelines
Pipelines	Length	Nominal Diameter	Max. Allowable Pressure	Capacity	Comm. in the year
	(Km)	(Inches)		(mmcf)

North - South	175	24	1135	350	1993
Rashidpur - Ashuganj	[75+82]=157	30,14	1135	500	2002/2004
Bibiyana - Muchai	42	30		600	2007
Ashuganj - Bakhrabad	58	30	1000	500	1998
Beanibazar - Kailashtila	18	20	1135	200	2001
Ashuganj - Elenga	124	24	1000	270	1992
Elenga - Baghabari	[14+9+16+35]=74	24,30,24,20	1000	200	1999
Bakhrabad -Demra	68	20	1000	250	1985
Bakhrabad - Chittagong	175	24	960	350	1982
Nalka - Bogra	[6+54] =60	30,20	1000	200	2005
Ashuganj - Monohordi	37	30	1000	425	2006
Dhanua - Aminbazar	60	20	1000		2006/2007
